Hokaido vacuum pump company sorts out some of the common faults of industrial vacuum pumps, and how to troubleshoot and repair methods for customer friends to refer to and use.
.jpg)
Common fault one: the vacuum pump cannot be started
Possible causes and corresponding repair methods:
1. The power cord is not connected correctly - check and repair the power cord;
2. The power supply voltage of the supply motor does not match the motor - replace the motor;
3. Motor failure - replace the motor;
4. Pump oil temperature is lower than 10 °C - heat the vacuum pump or use other types of vacuum pump oil;
5. The pump oil is too viscous - oil change;
6. The exhaust filter or exhaust pipe is blocked - cleaning the filter or exhaust pipe;
7. The pump is stuck - repair the pump.
Common fault two: the vacuum pump can not reach the limit pressure
Possible causes and corresponding repair methods:
1. The measurement method or regulation is not suitable - use the correct measurement method and regulation / directly measure the vacuum at the inlet of the pump;
2. Anti-return valve failure - maintenance of anti-return valve;
3. Exhaust valve failure - maintenance of exhaust valve;
4. Vacuum pump oil is not suitable - oil change (if necessary, the oil is degassed);
5. The air inlet is polluted - cleaning the pumping pipe;
6. The pumping speed of the pump is too small - confirm the system parameters, if necessary, change the pump.
.jpg)
Common fault three: the pumping speed is too slow
Possible causes and corresponding repair methods:
1. The air inlet or intake pipe is blocked - cleaning the intake pipe (installing a debris filter in front of the air inlet can prevent such failures);
2. The exhaust filter is blocked - replace the filter;
3. The diameter of the connected vacuum tube is too small or the pipe is too long - use a pipe with a large enough diameter or a short connecting pipe.
Common fault four: after stopping the pump, the pressure in the pumped container rises too fast
Possible causes and corresponding repair methods:
1. The vacuum system has a leak - check the system;
2. Anti-return valve failure - maintenance of anti-return valve.
Common fault five: the temperature of the vacuum pump is too high during operation
Possible causes and corresponding repair methods:
1. The air required for the cooling pump is blocked - the vacuum pump should be installed correctly (there should be enough space at the rear of the motor);
2. The ambient temperature of the pump is too high - reduce the ambient temperature, the maximum allowable ambient temperature is 40 °C;
3. The temperature of the pumped gas is too high - change the process;
4. The oil level is too low - refueling;
5. The oil is not suitable - oil change;
6. The circulation of vacuum pump oil is blocked - clear or maintenance of the oil inlet;
7. The exhaust filter or exhaust pipe is blocked - replace the filter core, clean the exhaust pipe;
8. Exhaust valve failure - repair exhaust valve;
9. The pump chamber is worn - replace the pump chamber components.
.jpg)
Common fault six: oil is found in vacuum pipes or pumped containers
Possible causes and corresponding repair methods:
1. The oil comes from the vacuum system - check the vacuum system;
2. Anti-return valve failure - cleaning or repairing the anti-return valve;
3. The sealing surface of the anti-return oil valve is worn or too dirty - cleaning or repairing the air inlet and the anti-return oil valve;
4. The oil level is too high - let go of the excess pump oil.
Common fault seven: vacuum pump oil turbidity, emulsification
Possible causes and corresponding repair methods: condensable gas condensation – degassing or oil change of oil and flushing the pump chamber can prevent such problems by opening the ballast valve in advance.
Common fault eight: the noise of the vacuum pump is too large
Possible causes and corresponding repair methods:
1. The oil level is too low (the oil can no longer be seen in the observation window) - refueling;
2. The silencer hole is blocked - cleaning or replacing the silencer hole components;
3. The pressure of the inlet is too high - reduce the pressure of the inlet;
4. The internal oil mist filter is blocked - cleaning or replacing the oil mist filter;
5. Elastic coupling body wear - replace a new elastic coupling body;
6. Damage to blades or bearings - repair the pump.
In the process of using the vacuum pump, when encountering a fault, you can follow the methods mentioned here to troubleshoot and repair them one by one; If you can't solve it yourself, please contact Hokaido vacuum pump manufacturer to consult for understanding, Good CapitaLand vacuum pump also provides convenient and efficient vacuum pump maintenance services.
